Landoll 825-AG DETACHABLE TRAILER

Name: Landoll 825-AG DETACHABLE TRAILER
Brand: Landoll
Availability: OutOfStock

Call for Price

Get a Quote Get Financed Value a Trade Contact Us Book a Demo Get Directions Get Directions Print

Overview

PROVEN SOLUTIONS

800 Series Ag Detachable Trailers are designed with an innovative four-beam frame and gooseneck give the operator versatility required to safely load and legally transport today’s heavy, wide and tall equipment.

VERSATILITY

The 800 frame design features a flat deck with a loaded height of 17” off the ground. Coupled with a low tare weight, the 825 can haul the latest combines, tillage, haying equipment and planters with up to 32′ of usable deck space.

SAFETY & PATENTED GOOSENECK DESIGN

A single hydraulic control lever lowers, detaches and activates the patented gooseneck carrier arms, which allows the ease and simplicity of detaching and loading directly onto the lower deck which is only 11¼” off the ground. You will never have to drive up and over the trunnion again.

Specifications

Model

825-AG

Category Name

Trailers

Year

2024

Sale Type

New

Manufacturer

Landoll

frame & general

Capacity*   27.5 Ton (55,000 lbs.)
Deck Rating   50,000 lbs. in 16′
Estimated Base Weight   16,400 lbs. (49′) 16,950 lbs. (51′)
Main Frame   Fabricated 10″, 100,000 PSI Flange
Deck Width   102″
Loaded Deck Height   17″
Loaded Ground Clearance   7″
Decking   1-1/2″ Apitong, Full Width
Crossmembers   5″ x 3″ High Tensile Tubing on 18″ Centers
Hitch   Automatic Gooseneck Lock Engagement
Gooseneck   12′
Pin Setting   15″
Swing Clearance   84″
Side Extension   27″ Aluminum Telescoping Extensions (Lower Deck) (Capacity-7,000 lbs. EACH Extension)
Tool Box   No Standard Tool Box
Gooseneck Tie Downs   D-Rings: 2 Each Front Corner; 2 Each Back
Lower Deck Tie Downs   Double Keyhole Chain Slots Located on 36″ Centers; Side Mounted Nylon Strap / Chain Tie Downs
Rear Trunnion Tie Downs   D-Rings: 2 Each at Base Flush Mounted on Top of Inner Beams; 2 Each at Rear Flush Mounted on Top of Inner Beams; 2 Each at Top of Slope on Outer Web

suspension & undercarriage

Air Raise and Lower Valve
Suspension   Neway Air Ride 25,000 lbs. Capacity
Grease   Centralized Grease System
Axles   (2 ) 25,000 lbs. Tandem Dual Tire, Oil Bath Bearings
Axles Prepped for Air Inflation
Brakes   16.5 x 7 Full Air / Spring Brakes Both Axles, ABS 4S2M, Automatic Slack Adjusters
Tires   255/70R 22.5 LRH Double Coin
Rims   22.5 x 8.25
Wheels   Steel Hub Pilot
Oil Seal Hubs   Internal Mated Assembly

hydraulics

Hydraulic Hook Up Quick Couplers 2,500 PSI – 20 GPM at Controls, 50GPM Max
Cylinders Gooseneck Cylinders Horizontally Mounted

electrical

Electrical   7-Way Receptacle
Air   Glad Hand
Lights   Grote Clear Lens LED with Chrome Bezel (10-year warranty)
Wiring Harness   Grote “Xtreme” Wiring Harness (7-year warranty)

finish & color

Finish   Steel Grit Shot Blast to Bright Metal
Powder Coat Color   White, Black, Yellow, Blue, Red, Green, Metallic Gray, Sapphire Blue
Decals   Hi-Visibility Reflective Package
